1400XH300 / Type XH Timing Belt of 140 in Pitch Length

Reference: 1400XH300
Description: 1400XH300 Standard inch Pitch Timing Belt
Length: 140 in Pitch Length
Number of teeth:160
Pitch: 0.875 in
Total Height: 0.44 in
Tooth Height: 0.25 in
Weight: 8.40 lb

$253.52

In stock

Description: 1400XH300 Standard Timing Belt
• Reference: 1400XH300
• Length: 140 in Pitch Length
• Number of teeth:160
• Pitch: 0.875 in
• Total Height: 0.44 in
• Tooth Height: 0.25 in
• Width: 3 in
• Weight: 8.40 lb
• Material: Flexible neoprene backing, fiberglass tensile cord as reinforcement
• Recommended use: – when the power is transmitted from the back of the belt.
• The 1400XH300 timing belts offer a reliable, economical and trouble-free alternative to chain drives. Compared to chain drives 1400XH300 belts are cleaner, lube-free, quieter and lower in cost. The 1400XH300 belts feature high temperature chloroprene polymer throughout. The high performance, woven, nylon based, fabric facing material has been engineered and tested for highly wear resistant performance.1400XH300The backing is precision ground for smooth uniform running. The 1400XH300 timing belts exceed USA RMA Standard IP-24 ratings levels and compare to the premium manufacturers ratings for Timing belts.

Number of Teeth	280
Top Width	3 in
Pitch	0.5 in
Belt Type	Timing Belt
Pitch Length	140 in
Material	Rubber
